| جزییات | مشخصات |
|---|---|
| Model | PC-240 |
| Output | 240W |
| Output regulation | Less than 3dB, no load to full load |
| Speaker output | Balanced 8 Ohm |
| AUX output | 600 Ohm / 1V(0dBV) |
| Inputs | Mic 1,2,3/600 Ohm,2.0Mv (-54dBV),unbalanced |
| Inputs | AUX 1,2/10 K Ohm,250mV (-10dBV),unbalanced |
| Frequency response | 100Hz~16KHz |
| Distortion | Less than 0.1% at 1KHz,1/3 rated power |
| Signal to noise ratio | Microphone 1,2,3 : 66dB |
| Signal to noise ratio | AUX 1,2 : 70DB |
| Tone | Bass: +- 10dB at 100Hz |
| Tone | Treble: +- 10dB at 10KHz |
| Muting function | Mic 1 overrides other input signals with 0~30dB attenuation |
| Protection | AC fuse; DC voltage, overload and short Circuit |
| Power Requirements | AC 220~240V/50~60Hz |
| Power Consumption | 320W |
| Dimension (mm) | 482mm*380mm*110mm |
| Weight | 12.3Kg |
